Micro Fiber Optic Splitter 1x8 SC UPC APC Fiber Optic PLC Splitter / Coupler

Micro Fiber Optic Splitter 1x8 SC UPC APC Fiber Optic PLC Splitter / Coupler
Micro Fiber Optic Splitter 1x8 SC UPC APC Fiber Optic PLC Splitter / Coupler Micro Fiber Optic Splitter 1x8 SC UPC APC Fiber Optic PLC Splitter / Coupler Micro Fiber Optic Splitter 1x8 SC UPC APC Fiber Optic PLC Splitter / Coupler

Large Image :  Micro Fiber Optic Splitter 1x8 SC UPC APC Fiber Optic PLC Splitter / Coupler

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: CE RoHS,ISO9001
Model Number: Circulator
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: 2pcs in a foam with plastic Box
Delivery Time: 2-7 work days
Payment Terms: T/T, Western Union
Supply Ability: 50000pcs per month
Contact Now
Detailed Product Description
Return Loss: ≥45dB Wavelengths: 1310±30 Or 1550±30 Or 1585±30
Power Handling: SMF-28e Or Customized Opterating Temperature: -10~+75
Use: FTTH Optical Connector:: C/APC&FC/APC&SC/PC
Output Level: >80dBuV Warranty Time: 13 Months, One Year
High Light:

Micro Fiber Optic Splitter

,

1x8 Fiber Optic Splitter

,

SC Fiber Optic PLC Splitter

Micro Fiber Optic Splitter 1x8 Sc Upc Apc Fiber Optic Plc Splitter / Couple



Features

Low Insertion Loss
Low PDL
High Uniformity
Good Environmental Stability


Applications

FTTH, PON, CATV, LAN
Local Ring Network
Optical Sensors System
Optical Test Instrument
Optical Communications System



Technical Specification

parameter
Index
Center Wavelength(nm)
1260～1650
Structure Type
1×4
1×8
1×16
1×32
2×4
2×8
2×16
2×32
Maximum Insertion Loss(dB)
7.4
10.7
13.7
16.9
7.6
11.2
14.5
18.2
Uniformity(dB)
0.6
0.8
1.2
1.7
1.0
1.5
2.0
2.5
PDL(dB)
≤0.20
≤0.30
≤0.30
≤0.30
≤0.30
≤0.30
≤0.40
≤0.40
Minimum Directivity (dB)
≥55
Return Loss(dB)
≥50
Operation Temperature(℃)
-40~+75
Storage Temperature(℃)
-40~+85
Package Dimension
Specified
Industry Standard
Telcordia GR-1221-CORE
Type of Package Dimension(mm)
1,40×4×4 2,50×7×4 3,100×80×9
4,120×80×18 5,140×115×18
