High Power Optical Circulator Small Size Bandwidth For Fiber Amplifier

Name: High Power Optical Circulator Small Size Bandwidth For Fiber Amplifier
Brand: GEZHI or OEM
SKU: High Power Optical Circulator
Rating: 4.7 (109 reviews)

Large Image : High Power Optical Circulator Small Size Bandwidth For Fiber Amplifier

Product Details:

Place of Origin:	China
Brand Name:	GEZHI or OEM
Certification:	CE RoHS,ISO9001
Model Number:	High Power Optical Circulator

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	Negotiable
Packaging Details:	Paper box
Delivery Time:	5-8 work days
Payment Terms:	T/T, Western Union
Supply Ability:	100000Channel per month

Contact Now

Detailed Product Description

Product Name:	High Power Circulator	Operating Temperature:	-5~+75(℃)
Storage Temperature:	-40~+85（℃）	Warranty:	3 Years
Application:	Fiber Amplifier
High Light:	High Power Optical Circulator , Optical Circulator For Fiber Amplifier

Product Overview of High Power Circulator

Low insertion loss 780-1080 nm High Power Optical Circulator for Fiber Amplifier

High Power Optical Circulator

GEZHI high power optical circulator is designed for high power applications. It features small size, bandwidth, stable performance, wide temperaturerange,high isolation, low loss, low standing wave,high The characteristics of intermodulation and high power

Features & Applications of High Power Circulator

Features:

High Channel Isolation
Low Insertion Loss
High Return Loss
High Stability & Reliability

Applications:

Fiber Amplifier
Testing Instrument
Medical Equipment

Specifications of High Power Circulator

Parameters	Unit	Value
Center Wavelength	nm	1064, 1030, 980	850, 808, 780
Operating Wavelength Range	nm	±5
Typ. Peak Isolation	dB	25	23
Min. Isolation at 23℃	dB	22	20
Typ. Insertion Loss at 23℃	dB	1.0	1.2
Max. Insertion Loss at 23℃	dB	1.3	1.5
Min. Extinction Ratio at 23℃ (PM Fiber Type)	dB	20	18
Max. Polarization Dependent Loss at 23℃ (SM Fiber Type)	dB	0.15
Min. Return Loss at 23℃ (Input/ Output)	dB	45
Min. Cross Talk	dB	45
Max. Average Optical Power (Including Port1 & Port2)	W	1, 2, 5, 10, 20 or Specified
Max. Peak Power for ns Pulse	kW	10 or Specified
Max. Tensile Load	N	5
Package Dimension	mm	70x28x26
Operating Temperature	℃	+10~+50
Storage Temperature	℃	0~+60

With connectors, the handling power is 1W only, IL is 0.3dB higher, RL is 5dB lower, and ER is 2dB lower.
Connector key is aligned to slow axis.

Odering Information of High Power Circulator

1111 - Wavelength:	1064=1064nm, 1030=1030nm, 980=980nm, 780=780nm, SSSS=Specified
2 - Port Type:	3=3-Port
3 - Working Axis:	B=Both axis working, F=Fast axis blocked, N=Non-PM
444 - Fiber Type:	003=PM980, 004=Hi1060, 007=780-HP, 067=PM780-HP, SSS=Specified
5 - Package Dimensions:	0=64x28x26mm, S=Specified
6 - Pigtail Type:	0=bare fiber, 1=900μm loose tube
7 - Fiber Length:	0.8=0.8m, 1.0=1m, S=Specified
888 - Connector Type:	0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, N=None, S=Specified
99 - Average Power:	00=300mW, 01=1W, 02=2W, 10=10W, 20=20W, SS=Specified
AA - Peak Power: -Peak Power:	00=Continuous Wave, 01=1kW, 02=2kW, 10=10kW, 20=20kW, SS=Specified

Package Dimension

High Power Optical Circulator Small Size Bandwidth For Fiber Amplifier 0

FAQ

Q1:Can I have a sample order? What is your MOQ of High Power Circulator?

A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available.  Also Mixed samples are acceptable.

Q2: What's the Lead time?

A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.

Q3: What are the payment terms?

A3: Payment term: T/T, Paypal, Western union,cash payment, Alibaba etc.

Q4: What is your warranty time of High Power Circulator?

A4: 3 years' warranty.

Q5: Could I use our own logo, label and package?

A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
