Product Details:
Payment & Shipping Terms:
|
| Data Rate: | Data Rate | Reach: | Reach |
|---|---|---|---|
| Wavelength: | 3V Or 5V | Length: | 1296, 1300, 1304, And 1309 Nm |
| Max Power: | 5.5W | Operating Temperature: | 0 To 70°C |
| Interface: | Duplex LC | Transmission Distance:: | 300m |
| Use: | Data Center |
high channel isolation 1x4 medichanical optical switch module
Product
| Technical Parameters | Descriptions |
| Model Number | YXF-PP-M85L-03D |
| Fiber type | MMF |
| Form Factor | Dual SFP+ |
| Data Rate | 10Gbps |
| Wavelength | 850nm |
| Distance | 300m |
| Sensitivity | <-14.0dBm |
| Connector | LC |
| Laser/Detector | VCSEL/PIN |
| DDM | Yes |
| Output Power | 1~-6 |
| Power Supply | 3.3 |
| Temperature | 0~70 |
| Certificate | CE,NOA,ROHS,ISO,FCC,SGS |
| Warranty | 1 Year |
Features
1. SFI electrical interface.
2. 2-wire interface for integrated Digital Diagnostic monitoring
3. 850nm VCSEL and PIN receiver.
4. Very low EMI and excellent ESD protection.
5. Power consumption less than 1.0W.
6. Hot-pluggable capability.
Advantages
1. The transceiver is a high performance, cost effective modules, which is optimized for 10G Ethernet application, and transmission distance up to 300m.
2. The module is hot pluggable into the 20-pin connector .
3. The transceiver incorporates TX_DIS control, TX-FAULT and RX_LOS monitor functions. The devices are Class I laser safety compliant.
Specification
|
|
Packing & Shipping
More Questions:
1. Can I have a sample order?What is your MOQ?
Yes, we welcome sample order to test and check quality. We do not have MOQ,1 sample is available.
2. What is the lead time?
For usual products,We keep stock,could ship about 3 days after received payment.For big quantity and special products,Please check lead time with our sales representative.
3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
4. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Paypal.
Could also support L/C,Credit terms.
5. What is your warranty time
We promise 3 years warranty for all products shipped from us.
6. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,we could accept free exchange.
7. Could i use our own logo and label?
Yes,we could provide a OEM service and make the products with your own label.
