1x4 MEMS Optical Switch Module for Data Center with Fast Switching Time and Fiber Optical Connectivity

Name: 1x4 MEMS Optical Switch Module for Data Center with Fast Switching Time and Fiber Optical Connectivity
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: 1x4 MEMS Optical Switch
Price: 1,212.00 USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	1x4 MEMS Optical Switch
MOQ:	1pc
Price:	US$369-US$2056
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Wavelength Range:

1260~1650 For SM,850/1310 For MM

Packaging Details:

Paper box

Highlight:

MEMS 1x4 Module

1x4 MEMS Optical Switch

Fiber Sensing 1x4 Module

Product Description

MEMS 1x4 Module Data Center Fiber Sensing And Monitoring 1x4 MEMS Optical Switch

Product Overview

Gezhi Photonics MEMS 1X4 Fiber Optical Switch is a compact, single mode or multimode fiber optical switch configurable for port counts up to 1x64. Utilizing proprietary microelectromechanical system (MEMS) technology, this switch delivers reliable optical performance and excellent durability. Available in any 1XN size up to 1x64, including 1x4, 1X8, 1X9, 1X10, 1X12, 1X16, 1X24, 1X32, 1X36, 1X48, and 1x64 configurations.

Key Features

Based on advanced MEMS technology
1XN configurations up to 1x64 in compact package
High stability and reliability
Low insertion loss with fast switching time
Available in single mode and multi-mode versions

Applications

Optical reconfiguration
Optical network protection/restoration
Network security and monitoring
R&D in laboratory environments
Secure communications systems

Technical Specifications

Single Mode Specifications

Parameter	Specification
Wavelength range (nm)	1240~1640
Insertion loss (dB)	≤1.5 (Typ 1.0)
Crosstalk (dB)	≥ 60 (Typ 75)
Backreflection (dB)	≥ 50 (Typ 55)
Polarisation Dependent Loss (dB)	≤0.12
Switch time (ms)	≤1 (Typ 0.5)
Switching Voltage (V)	5
Fiber Pigtail (µm)	9/125/900
Durability (cycles)	no wear out
Power Consumption (mW)	≤50 (Typ 10)
Operation temperature(℃)	0~70
Storage temperature (℃)	-40~85
Package Size (L x W x H) (mm)	80 x 50 x 9.5

Multi-Mode Specifications

Parameter	Specification
Wavelength range (nm)	700 ~ 1700
Insertion loss (dB)	≤1.5 (Typ 1.0)
Crosstalk (dB)	≥ 45 (Typ 55)
Backreflection (dB)	≥ 35 (Typ 45)
Polarisation Dependent Loss (dB)	≤0.15
Repeatability (dB)	≤0.001
Switch time (ms)	≤20 (Typ 2)
Switching Voltage (V)	5
Fiber Pigtail (µm)	62.5/125/900 or 50/125/900
Durability (cycles)	no wear out
Supply Voltage (V)	4.0~5.25 (Typ:5)
Power Consumption (mW)	≤50 (Typ 10)
Operation temperature(℃)	0~70
Storage temperature (℃)	-40 ~ 85
Package Size (L x W x H) (mm)	80 x 50 x 9.5

Ordering Information

Type	Channel	Wavelength	Fiber Type	Fiber Diameter	Fiber Length	Connector
GZ-MEMS	01=1x1 02=1x2 ... 16=1x16 ...	85=850nm 13=1310nm 14=1490nm 15=1550nm 1625=1625nm 1650=1650nm 13/15=1310/1550nm	5=50/125 6=62.5/125 9=9/125 X=Others	25=250um 90=900um 20=2.0mm 30=3.0mm X=Others	1=1m 2=1.5m X=Others	00=none LP=LC/UPC LA=LC/APC SP=SC/UPC SA=SC/APC FP=FC/UPC FA=FC/APC MP=MPO X=Customized

Please reference the coding system above when placing your order.
