LC Connector Type DWDM Mux Demux with 5%~95% Relative Humidity and ≤10W Power Consumption

Name: LC Connector Type DWDM Mux Demux with 5%~95% Relative Humidity and ≤10W Power Consumption
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: DWDM Mux Demux
Price: 515.00 USD
Availability: InStock

Brand Name:	GEZHI
Model Number:	DWDM Mux Demux
MOQ:	1
Price:	UU$350-US$680

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Product Name:

DWDM Mux Demux

Relative Humidity:

5%~95%

Return Loss:

≥50dB

PDL:

≤0.2dB

Power Consumption:

≤10W

Insertion Loss:

≤7.0dB

Connector Type:

LC, SC, FC, ST

Storage Temperature:

-40℃~+85℃

Highlight:

LC Connector Type Multiplexing Device

95% Humidity Multiplexing Device

RoHS DWDM Mux Demux

Product Description

LC Connector Type Wavelength Multiplexing Device

Product Overview

DWDM Mux Demux is a high-performance Dense Wavelength Division Multiplexer designed for efficient wavelength multiplexing and demultiplexing in high-speed optical networks. This device provides reliable signal transmission over long distances with excellent performance characteristics.

Key Features

Product Name: DWDM Mux Demux
Connector Types: LC, SC, FC, ST
Power Consumption: ≤10W
Operating Humidity: 5%~95% Relative Humidity
Insertion Loss: ≤7.0dB
Multiple Channel Count Options: 4 to 1536 channels
Dense Wavelength Division Multiplexer Technology

Technical Specifications

Parameter	Specification
Package Types	1U, 2U, 4U, 6U, 8U, 10U
Insertion Loss	≤7.0dB
Channel Count Options	4, 8, 16, 32, 40, 80, 96, 120, 144, 160, 192, 240, 288, 320, 336, 384, 432, 480, 576, 640, 768, 864, 960, 1040, 1152, 1280, 1536
Operating Temperature	-40℃ to +85℃
Relative Humidity	5% to 95%
Channel Spacing	100GHz, 50GHz, 20GHz, 10GHz, 5GHz
Polarization Mode Dispersion	≤0.2ps
Wavelength Bands	C-Band, L-Band
PDL (Polarization Dependent Loss)	≤0.2dB

Applications

GEZHI DWDM Mux Demux provides high-performance transmission and flexible management for optical fiber networks. Characterized by high reliability, low insertion loss, low polarization dependence loss, low temperature dependence loss, and high stability. Certified with CE RoHS and ISO9001 standards.

Packaging & Shipping

The DWDM Mux Demux is carefully packaged to ensure safe transit:

Unit placed in static dissipative bag within protective box
Foam-lined packaging on all sides for impact protection
Clear labeling with product information and shipping details
Shipped via reliable carriers with tracking and insurance options
Compliance with all local and international shipping regulations

Frequently Asked Questions

What is GEZHI DWDM Mux Demux?

GEZHI DWDM Mux Demux is a device used to multiplex and demultiplex different wavelengths of light in a DWDM (Dense Wavelength Division Multiplexing) system.

What is the model number?

The model number is DWDM Mux Demux.

Where is GEZHI DWDM Mux Demux manufactured?

GEZHI DWDM Mux Demux is made in China.

What certifications does it have?

GEZHI DWDM Mux Demux is certified with CE RoHS and ISO9001.

What is the minimum order quantity?

The minimum order quantity is 1 unit.
