1% Monitor Optical Passive WDM CWDM DWDM 500mw ITU For Telecom Networks

1% Monitor Optical Passive WDM CWDM DWDM 500mw ITU For Telecom Networks
1% Monitor Optical Passive WDM CWDM DWDM 500mw ITU For Telecom Networks

Large Image :  1% Monitor Optical Passive WDM CWDM DWDM 500mw ITU For Telecom Networks

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: RoHS ,ISO9001
Model Number: CWDM8A47LLP
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Paper box
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 100000Channel per month
Detailed Product Description
Product Name: Passive WDM CWDM DWDM Wavelength: 1470,1490,1510,1550,1570,1590,1610
Port: 8 Channel Line Type: Dual Fiber
Connector: LC/UPC BOX Package: LGX Chassis
High Light:

500mw WDM CWDM DWDM

,

Optical Passive WDM CWDM DWDM

,

ITU Passive Cwdm Mux

1% Monitor Optical Passive WDM CWDM DWDM in Telecom Networks



1% Monitor Optical Passive WDM CWDM DWDM in Telecom Networks is part of our xWDM product line uses up to 18 CWDM(Coarse Wavelength Division Multiplex) optical channel plan as defined by ITU-T G.694.2 allowing to organize up to 18 parallel and independent data streams over pair of single-mode optical fibers using CWDM multiplexing. xWDM technology remains as today’s prevailing technology for extending black fiber capacity.



Features

ITU CWDM Grid

CWDM Mux/Demux/OADM

Low Loss & Highly Reliable

Applications

Optical Add/Drop Multiplexing

Telecom Networks

Metro Networks



1% Monitor Optical Passive WDM CWDM DWDM in Telecom Networks

Specification

Parameter Passive WDM CWDM DWDM
Center Wavelength (nm) ITU, ITU+1
Passband (nm) ITU±7.5
Operating Wavelength (nm) 1470~1610nm
Channel Space (nm) 20
Fiber Type SMF-28e or customer specified
IL (dB) <2.5dB
Isolation(dB) Adjacent Channel 30
  Non-Adjacent Channel 45
PDL (dB) 0.2
PMD (ps) 0.1
Return Loss (dB) 45
Directivity (dB) 50
Maximum Optical Power (mw) 500
Operating Temperature (℃) -20~+70
Storage Temperature (℃) -40~85
BOX Package (mm) LGX chassis



Ordering Information

CWDM Number of Channels Configuration First Channel Last Channel Module type Cable type Fiber length Connector

CWDM

01=1 CH
02=2 CH
03=3 CH
......
16=16CH
17=17CH
18=18CH

......

M=Mux

D=Demux

A=Mux+Demux

27=1270

29=1290

......



47=1470

S=Specify

27=1270

29=1290

......



47=1470

S=Specify

A1=ABS box 100x80x10mm

A2=ABS box 120x80x18mm

A3=ABS box 140x115x18mm

L1=LGX 129*29*130mm

L2=LGX insert in 2slot Rack

L4=LGX insert in 4slot Rack

R1=19" 1 U Rack

R2=2slot 19″1U Rack

R4=4slot 19″1U Rack

S=Specify



09=900um loose tube
20=2.0mm
30=3.0mm

05=0.5m

10=1.0m
15=1.5m
S=Specify

00=none
LP=LC/UPC
LA=LC/APC
SP=SC/UPC
SA=SC/APC
FP=FC/UPC
FA=FC/APC
S=Specify
