1x4 Polarization Maintaining PM Filter WDM Module FC / APC Connector

1x4 Polarization Maintaining PM Filter WDM Module FC / APC Connector
1x4 Polarization Maintaining PM Filter WDM Module FC / APC Connector

Large Image :  1x4 Polarization Maintaining PM Filter WDM Module FC / APC Connector

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: CE RoHS,ISO9001
Model Number: WDM1x4PM
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Paper box
Delivery Time: about 10 work days
Payment Terms: T/T, Western Union
Supply Ability: 5000Channel per month
Detailed Product Description
Product Name: PM Filter WDM Module Wavelength: 1397/1550/1626nm
Channel Number: 1x4 Line Type: Single Fiber
Connector: FC/APC Application: WDM Network
High Light:

1x4 PM Filter WDM Module

,

FC APC WDM Module

,

1626nm WDM Module

1x4 Polarization Maintaining PM Filter WDM Module FC/APC Connector

Quick detail Of CWDM Mux Demux

Type: PLC splitter, Optical 1x8 Splitter

Directivity: ≥ 55 db

Application: FTTH, FTTB, FTTO, FTTx

Model: Mini Module PLC Splitter, Mini type PLC Splitter

Color: Customized, yellow,orange, up to request

Material: ABS

Product Name: PLC fiber Optic Splitter, PLC Splitter

Tail cable: 900um/2.0mm/3.0mm loose tool

Certification: CE, RoHS



Features

Polarization Maintaining
Low Insertion Loss
Epoxy-Free Optical Path
High stability and reliability

Customized Wavelength



Applications

  • Fiber to The Home (FTTH)
  • Passive optical networks (PON)
  • Local Area Networks (LAN)
  • Cable Television (CATV)
  • Test Equipment
  • FTTX Systems
  • PON Networks
  • CATV Links
  • Optical Signal Distribution



Specification

Parameter 1x4 PM Filter WDM
Operating Wavelength (nm) 1379/1397/1550/1626nm
1397nm Port 1383.5-1398.5nm
1550nm Port  1550+/-7.5nm
1626nm Port 1600~1670nm
1379nm Port 1260~1580 except1383.5-1398.5nm and 1550+/-7.5nm
Fiber Type PM fiber
IL (dB) <1.5dB
Isolation(dB) Adjacent Channel 30
  Non-Adjacent Channel 40
PDL (dB) 0.2
PMD (ps) 0.1
Return Loss (dB) 45
Directivity (dB) 50
Maximum Optical Power (mw) 500
Operating Temperature (℃) -5~+70
Storage Temperature (℃) -40~85
Connector FC/APC
BOX Package (mm) ABS box





1x4 PM Filter WDM cascading

1x4 Polarization Maintaining PM Fliter WDM Module FC/APC connector



1x4 Polarization Maintaining PM Filter WDM Module FC / APC Connector 0



Using Panda Fiber

1x4 Polarization Maintaining PM Filter WDM Module FC / APC Connector 1
