16 Channels 100Ghz DWDM Mux Demux Module ITU-T Grid LC UPC Connectors

16 Channels 100Ghz DWDM Mux Demux Module ITU-T Grid LC UPC Connectors
16 Channels 100Ghz DWDM Mux Demux Module ITU-T Grid LC UPC Connectors

Large Image :  16 Channels 100Ghz DWDM Mux Demux Module ITU-T Grid LC UPC Connectors

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: CE RoHS FCC,ISO9001
Model Number: 16CH-DWDM mux demux
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Paper box
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 100000Channel per month
Detailed Product Description
Features: High Stability And Reliability Wavelength: ITU-T Grid @DWDM
Channel Passband: 0.8nm (100Ghz) Line Type: Single Fiber
Connector: LC/UPC Or Customized
High Light:

100Ghz DWDM Mux Demux Module

,

LC UPC DWDM Mux Demux Module

,

0.8nm DWDM Mux Demux

16 Channels 100Ghz DWDM Mux Demux modules with SC/APC connectors



100Ghz DWDM Mux Demux is used to provide 100G transport solution for DWDM networking system. The common configuration is 4, 8, 16, 32, 40, 44 channels, standard 100G Mux/Demux package includes ABS box package, LGX package and 19" 1U rackmount. DWDM multiplexer/demultiplexer components based on Silica-on-Silicon technology that provides for low insertion loss and passive athermal operation.

GEZHI Photonics provides 100Ghz DWDM MUX & DEMUX modules with different input and output fibers, such as Single-mode fibers, Multimode fibers and polarization maintaining PM fiber, which can be selected to meet different applications. Custom frequency grids, fiber types and connector options are also available.



Features

Low Insertion Loss

High stability and reliability

High channel

Wide pass band

Epoxy-Free Optical Path

Telcordia GR-1221 Compliant



Applications

Access / Enterprise Networks

Long Haul Networks

CATV Fiber Optic Links

Wavlength Routing

Channel Add/Drop

Dense WDM Systems
Metro Networks



Specification

Parameter Unit 100Ghz DWDM Mux or Demux
Channel Number -- 16CH 17CH
Operation Wavelength nm C26~32&C34~C41+1% Monitor  C25~C41+1% Monitor Port
Channel Central Wavelength nm ITU-T Grid @DWDM
Channel Passband nm 0.8 (100Ghz)
Insertion Loss @PB dB <4.2 <4.5
Isolation @Adjacent Channel dB >30
Isolation @Non-adjacent Channel dB >34
Isolation @Reflect Channel dB >15
Passband Ripple dB <0.5
Polarization Dependent Loss dB <0.15
Polarization Mode Dispersion ps <0.1
Directivity & Return Loss dB Directivity: >50 Return Loss:>45
Power Handling mW <500
Connector -- SC/UPC or customized
Fiber Type -- SMF-28e or Customized
Operating Temperature -10 ~ +70
Storage Temperature -40 ~ +85
Package Dimension mm ABS box 120*80*18mm or customized



16 Channels 100Ghz DWDM Mux Demux Module ITU-T Grid LC UPC Connectors 0



16 Channels 100Ghz DWDM Mux Demux Module ITU-T Grid LC UPC Connectors 1



FAQ

Q: Are you trading company or manufacturer?
A: We are original manufacturer Of CWDM Mux Demux. We can do OEM/ODM business.

Q: How long is your delivery time?
A: Group buying delivery time: 30-60 days; General delivery time: 20 days.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.

Q: What is the warranty ?
A: The free warranty is one year from the day of Commissioning qualified.If there is any fault for our products within the free warranty period, we will repair it and change the fault assembly for free.
