FTTH 1x8 SC/UPC Fiber Optical Distribution Box with Fast Switching Time and 3 Years Warranty

Name: FTTH 1x8 SC/UPC Fiber Optical Distribution Box with Fast Switching Time and 3 Years Warranty
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: OSW-1x8-13/15-U
Price: 693.00 USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	OSW-1x8-13/15-U
MOQ:	1pc
Price:	US$398-US$988
Delivery Time:	2-7 work days
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Wavelength Range:

850±40/1300±40, 1260~1650

Packaging Details:

2pcs in a foam with plastic Box

Supply Ability:

50000pcs per month

Highlight:

fttx fiber optical distribution box

1x8 fiber optical distribution box

ftth fiber distribution box

Product Description

FTTX FTTH 1x8 SC/UPC Fiber Optical Distribution Box with PLC Splitter or Pigtail

GEZHI Series 1x8 Type fiber optical switches connect optical channels by directing or blocking incoming optical signals into output fibers. The latching version preserves the selected optical path after the drive signal is off, while non-latching versions default to either open or closed states when power is off. This 1x8 Mechanical Optical Switch features integrated electrical position sensors and advanced design that significantly reduces moving part position sensitivity, offering high stability, reliability, and low insertion loss.

Features

Low Insertion Loss
Low Optical Distortions
High Stability
High Reliability
Epoxy-free on Optical Path

Applications

MAN (Metropolitan Area Network)
R&D in Laboratory
System Monitoring
Instrumentation

Specifications

Parameter	Unit	OSW-1x8-U or OSW-1x16-U
Wavelength Range	nm	850±40/1300±40 \| 1260~1650
Operating Wavelength	nm	850/1300 \| 1310/1550
Insertion Loss	dB	Typ. ≤0.8dB, Max.≤1.5 dB \| Typ. ≤0.8dB, Max.≤1.5 dB
Return Loss	dB	MM≥30 SM≥50
Crosstalk	dB	MM≥35 SM≥55
Polarization Dependent Loss	dB	0.05
WDL	dB	≤0.25
TDL	dB	≤0.25
Repeatability	dB	≤±0.02
Power Supply	V	AC:100～240 (50/60Hz)
Lifetime	times	≥10⁷
Switch Time	ms	≤10
Optical Power	mW	≤500
Operating Temperature	℃	-20~+75 (-40~+85 available)
Storage Temperature	℃	-40~+85
Dimension	mm	1U:483 x 230 x 44

Product Images

Product Packaging

Finished Item	Inner Package	Inner Box	Carton
FTTX FTTH 1x8 Distribution Box	Standard protective packaging	Individual box	Master carton
