1x4 Ports Single Mode Fiber Switch Non Latching

1x4 Ports Single Mode Fiber Switch Non Latching

1x4 Ports Single Mode Fiber Switch Non Latching

Brand Name:	GEZHI or OEM
Model Number:	OSW-1x4-13/15
MOQ:	1pc
Price:	Negotiable
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Type:

FTTx Solutions

Control Type:

Latching Or Non Latching

Warranty Time:

3 Years

Application:

Ring Network

Port:

1x4

Name:

1x4 Ports Single Mode Fiber Switch Non Latching

Packaging Details:

Paper box

Supply Ability:

100000Channel per month

Highlight:

1x4 ports single mode fiber switch

,

Non Latching single mode fiber switch

,

singlemode switch fiber optic 4 port

Product Description

Product Overview

1x4 Multi Channel Optical Switches

GEZHI 1×4 Multi-Channele Fiber Optical switches is a kind of functional component, with the ability of switching optical route. In optical fiber transmission system, it is used for multi light source/ detector selection, multi-channel fiber monitoring, and ptical fiber path protection etc. Besides, it is also used in optical fiber test system for optical fiber and its component test,outdoor cable test and multi-spot optical sensors monitoring system.


FEATURES AT A GLANCE

Low Insertion Loss

More Than 128 Channels

High Stability & Reliability

Parallel Interface (TTL)

Modularized Design

Customzied Wavelength available

1x4 Ports Single Mode Fiber Switch Non Latching 0

1x4 Ports Single Mode Fiber Switch Non Latching 1

PRODUCT SPECIFICATIONS


			Parameter

			Unit

			OSW-1x4

			Wavelength Range

			nm

			850±40/1300±40

			1260~1650

			Operating Wavelength

			nm

			850/1300

			1310/1550

			Insertion Loss

			dB

			<1.2

			<1.0

			Return Loss

			dB

			MM≥30 SM≥50

			Crosstalk

			dB

			MM≥35 SM≥55

			Polarization Dependent Loss

			dB

			0.05

			WDL

			dB

			≤0.25

			TDL

			dB

			≤0.25

			Repeatability

			dB

			≤±0.02

			Power Supply

			V

			5.0 or 12v

			Lifetime

			times

			≥107

			Switch Time

			ms

			≤8

			Optical Power

			mW

			≤500

			Operating Temperature

			℃

			-20~+75 (-40~+85 available)

			Storage Temperature

			℃

			-40~+85

			Dimension

			mm

			135×64×32

FAQ

Q1:Can I have a sample order? What is your MOQ?A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available.  Also Mixed samples are acceptable.
Q2: What's the Lead time?
A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q3: What are the payment terms?
A3: Payment term: T/T, Paypal, Western union,cash payment, ALI etc.
Q4: What is your warranty time

A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?

A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
