Good price online

products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Fiber Optical Switches
Created with Pixso. Low Crosstalk Bi-directional 2x2F Fiber Network Switch with 3V or 5V Opto-Mechanical Optical Switch
Low Crosstalk Bi-directional 2x2F Fiber Network Switch with 3V or 5V Opto-Mechanical Optical Switch
  • name
  • name
  • name
  • name
  • name

Low Crosstalk Bi-directional 2x2F Fiber Network Switch with 3V or 5V Opto-Mechanical Optical Switch

Brand Name: GEZHI or OEM
Model Number: 2x2F-SM-13/15-5N
MOQ: 1pc
Price: US$58-US$118
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Fiber Connector:
LC/UPC, FC/APC, SC/APC Etc.
Packaging Details:
Paper box
Supply Ability:
5000pcs per month
Highlight:

Low Crosstalk fiber network switch

,

2x2F fiber network switch

,

Full Mechanical fiber optic network switch

Product Description
Low Crosstalk 2x2F Fiber Network Switch Full Mechanical
Product Overview

2x2 Full Opto-Mechanical Optical Switches

The 2x2F Bi-directional Fiber Optic Switch connects optical channels by redirecting 2 incoming optical signals into 2 output fibers. This is achieved using an opto-mechanical configuration and activated via an electrical control signal. The switch has integrated electrical position sensors.

Based on thin film filter technology that provides a robust method of altering the light path, this series of products has a drastically simplified platform configuration offering high reliability and low production cost. This novel design significantly reduces moving part position sensitivity, offering unprecedented high stability as well as an unmatched low cost.

Key Features
  • Low Insertion Loss
  • Low Crosstalk
  • High Stability, High Reliability
  • Epoxy-free on Optical Path
Applications
  • MAN (Metropolitan Area Network)
  • R&D in Laboratory
  • System Monitoring
  • Configurable OADM
Product Specifications
Parameter Unit 2x2F Optical Switch
Wavelength Range nm 850±40/1300±40 | 1260～1650
Operating Wavelength nm 850/1300 | 1310/1550
Insertion Loss dB <1.2
Return Loss dB MM≥30 SM≥50
Crosstalk dB MM≥35 SM≥55
Polarization Dependent Loss dB 0.05
WDL dB ≤0.25
TDL dB ≤0.25
Repeatability dB ≤±0.02
Power Supply V 3.0 or 5.0
Lifetime times ≥10⁷
Switch Time ms ≤8
Optical Power mW ≤500
Operating Temperature ℃ -20~+75 (-40~+85 available)
Storage Temperature ℃ -40~+85
Dimension mm (L)27.0×(W)12.0×(H)8.2
Product Images
Low Crosstalk Bi-directional 2x2F Fiber Network Switch with 3V or 5V Opto-Mechanical Optical Switch 0 Low Crosstalk Bi-directional 2x2F Fiber Network Switch with 3V or 5V Opto-Mechanical Optical Switch 1 Low Crosstalk Bi-directional 2x2F Fiber Network Switch with 3V or 5V Opto-Mechanical Optical Switch 2
Frequently Asked Questions
Q1: Can I have a sample order? What is your MOQ?
A1: Sample order is welcome to test and check quality. We don't have MOQ, 1pc sample is available. Mixed samples are acceptable.
Q2: What's the Lead time?
A2: The normal lead time is about 1 week. For large quantity and special products, please check lead time with our sales representative. We keep stock for some products and could ship within 1-3 days after receiving payment.
Q3: What are the payment terms?
A3: Payment terms: T/T, PayPal, Western Union, cash payment, AliPay, etc.
Q4: What is your warranty time?
A4: 3 years warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we provide OEM service according to your requirements, including custom product labels, logos, part numbers, serial numbers, and packaging.
Tags:

Latching Optical Switch

1550nm Fiber Optical Switches

2x2 Fiber Bypass Switch
