1x8 CWDM Mux Demux Module 1470~1610nm Single Core Fiber with LC/UPC ST/UPC Connectors for Data Center

Name: 1x8 CWDM Mux Demux Module 1470~1610nm Single Core Fiber with LC/UPC ST/UPC Connectors for Data Center
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: 1*8 CWDM
Price: 399.98 USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	1*8 CWDM
MOQ:	1pc
Price:	Negotiable
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Warranty Time:

3 Years

Use:

WDM System

Channel Spacing:

20nm

Center Wavelength:

1270~1610nm

Fiber Connector:

LC/UPC, FC/APC, SC/APC Etc.

Application:

Data Center

Fiber Type:

SMF-28e

Channel Number:

4, 8, 16, 18 Or Customized

Packaging Details:

Paper box

Supply Ability:

5000pcs per month

Highlight:

LC/UPC CWDM Mux Demux

1*8 CWDM Mux Demux

1470~1610nm CWDM Mux Demux

Product Description

CWDM Single Core Fiber Multiplexer/Demultiplexer Module

1×8 CWDM Passive Multiplexer Splitter WDM Module with LC/UPC ST/UPC Express Ports, 1470-1610nm Wavelength Range

Product Overview

CWDM Mux/Demux (optical multiplexer/demultiplexer) modules provide a cost-effective alternative to DWDM systems for metro access network applications. With wide channel spacing of 20nm, these systems eliminate the need for precise wavelength control, enabling the use of cost-effective non-cooled lasers and lower-cost passive components.

Technical Specifications

Parameter	Unit	CWDM Mux Demux
Channel Spacing	nm	20nm
Center Wavelength	nm	1270-1610 or 1271-1611
Channel Passband	nm	±6.5
Channel Number	/	4CH \| 8CH \| 16CH
Insertion Loss	dB	<1.5 \| <2.5 \| <5.5 or <3.5 (with skip)
Isolation @Adjacent Channel	dB	>30
Isolation @Non-adjacent Channel	dB	>40
Isolation @Express Port	dB	>15
Polarization Dependent Loss	dB	<0.2
Polarization Mode Dispersion	dB	<0.1
Directivity	dB	>50
Return Loss	dB	UPC >45 APC>50
Power Handling	mW	<500 (High Power type available)
Fiber Type	/	SMF-28e (Polarization Maintaining Type available)
Operating Temperature	℃	-20 to +75 (-40 to +85 available)
Storage Temperature	℃	-40 to +85
Package Type	mm	ABS Box, ABS Plug-in Module, LGX Chassis, Rackmount

Key Features

Low Insertion Loss
Stainless Steel tube construction
Multiple package options: ABS Box, ABS Plug-in Module, LGX Chassis, Rackmount
Customized package types available
High Isolation performance
High Stability & Reliability
Industrial Operating Temperature range (-40 to +80℃ available)

Frequently Asked Questions

Can I have a sample order? What is your MOQ?

Sample orders are welcome for quality testing. We have no minimum order quantity - even 1 piece samples are available. Mixed samples are also acceptable.

What's the Lead time?

Normal lead time is approximately 1 week. For large quantities and special products, please check with our sales representative. We maintain stock for some products and can ship within 1-3 days after payment.

What are the payment terms?

We accept T/T, PayPal, Western Union, cash payment, and ALI payments.

What is your warranty time?

3 years warranty coverage.

Could I use our own logo, label and package?

Yes, we provide OEM services according to your requirements, including custom product labels, logos, part numbers, serial numbers, and packaging.
