8 Channels Low Insertion Loss High Stability DWDM Mux Demux Dense WDM Module for Data Center

Name: 8 Channels Low Insertion Loss High Stability DWDM Mux Demux Dense WDM Module for Data Center
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: 8 Channels DWDM Mux/Demux Module
Price: 230.00 USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	8 Channels DWDM Mux/Demux Module
MOQ:	1pc
Price:	US$180-US$280
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Type:

FTTx Solutions

Use:

WDM System

Channel Spacing:

100GHz

Fiber Type:

SMF-28e

Application:

Data Center

Fiber Connector:

LC/UPC, FC/APC, SC/APC Etc.

Packaging Details:

Paper box

Supply Ability:

5000pcs per month

Highlight:

CATV DWDM Mux Demux

3 Years Warranty DWDM Mux Demux

8 Channels DWDM Mux Demux

Product Description

High Quality 3 Years Warranty Optical Fiber 8 Channels DWDM Mux/Demux Module for CATV

Product Overview

GEZHI Dual Fiber 8CH Dense WDM Mux and Demux module is a low insertion loss, high density passive optical module based on thin film coating technology with C33, C34, C35, C36, C37, C38, C39, C40 wavelengths. This compact module packages both 8CH DWDM mux and 8CH DWDM demux in a plug-in LGX Cassette with LC/UPC adapters, making it ideal for long-haul transport of fiber optic signals over dual fiber networks.

Key Features

High channel capacity
Wide pass band performance
Low Insertion Loss
High stability and reliability
Epoxy-Free Optical Path

Applications

Long Haul Networks
Wavelength Routing
Channel Add/Drop
CATV Fiber Optic Links
Dense WDM Systems

Product Images

Technical Specifications

Parameter	Unit	8CH Dense WDM Mux and Demux Module
Channel Number	--	8 Channel
Operation Wavelength	nm	C33~C40 or other wavelength
Channel Central Wavelength	nm	ITU-T Grid @DWDM
Channel Passband	nm	0.8 (100Ghz)
Insertion Loss @PB	dB	<2.5
Isolation @Adjacent Channel	dB	>30
Isolation @Non-adjacent Channel	dB	>40
Isolation @Reflect Channel	dB	>15
Passband Ripple	dB	<0.5
Polarization Dependent Loss	dB	<0.15
Polarization Mode Dispersion	ps	<0.1
Directivity & Return Loss	dB	Directivity: >50 Return Loss:>45
Power Handling	mW	<500
Connector	--	LC/UPC
Fiber Type	--	SMF-28e or Customized
Operating Temperature	℃	-20 ~ +70
Storage Temperature	℃	-40 ~ +85
Package Dimension	mm	130x129x29

Frequently Asked Questions

Q1: Can I have a sample order? What is your MOQ?

A1: Sample orders are welcome for quality testing. We have no minimum order quantity - even 1 piece samples are available. Mixed samples are also acceptable.

Q2: What's the Lead time?

A2: Normal lead time is approximately 1 week. For large quantities and special products, please check lead time with our sales representative. We maintain stock for some products and can ship within 1-3 days after payment confirmation.

Q3: What are the payment terms?

A3: We accept T/T, PayPal, Western Union, cash payment, and ALI payments.

Q4: What is your warranty time?

A4: 1 year warranty included with all products.

Q5: Could I use our own logo, label and package?

A5: Yes, we provide comprehensive OEM services according to your requirements, including custom product labels, logos, part numbers, serial numbers, and packaging.
