12Core Data Center Om4 Red Rose Round Mtp Mpo Optical Cable Patch Cord

Large Image : 12Core Data Center Om4 Red Rose Round Mtp Mpo Optical Cable Patch Cord

Product Details:

Place of Origin:	China
Brand Name:	GEZHI or OEM
Certification:	CE RoHS,ISO9001
Model Number:	OM4 MPO Fiber Cable

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	Negotiable
Packaging Details:	Paper box
Delivery Time:	5-8 work days
Payment Terms:	T/T, Western Union
Supply Ability:	100000Channel per month

Contact Now

Detailed Product Description

Warranty:	3 Years	Application:	Data Center, Data Center
Fiber Count:	12 /24 /48/96/144 Cores	Connector Type:	Female Or Male
Outer Jacket:	LSZH,OFNP ,OFNR	Mode:	OM4 Multimode

12Core Data Center Om4 Red Rose Round Mtp Mpo Optical Cable Patch Cord

MPO OM4 Patch Cord

GEZHI offers P grade OM4 MPO fiber optic patch cords.Its comes with multimode fiber appliies to high density in data center or telecommunication systems.

Specifications

Performance Level			Standard		Elite
Connector	Mode	Endface	IL(max) (dB)	RL(min) (dB)	IL(max) (dB)	RL(min) (dB)
MPO/MTP	MM OM4	8F/APC	≤0.50	≥20	≤0.35	≥20
		12F/APC	≤0.50	≥20	≤0.35	≥20
		24F/APC	≤0.50	≥20	≤0.35	≥20
		8F/PC	≤0.50	≥20	≤0.35	≥20
		12F/PC	≤0.50	≥20	≤0.35	≥20
		24F/PC	≤0.50	≥20	≤0.35	≥20

Recommed Products

12Core Data Center Om4 Red Rose Round Mtp Mpo Optical Cable Patch Cord 0

Product Package

Finished Item Inner package Inner Box
