Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching

Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching
Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching

Large Image :  Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: CE RoHS,ISO9001
Model Number: 1x1 Optical Switch
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Paper box
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 100000Channel per month
Detailed Product Description
Wavelength: 1260-1650nm Voltage: 3v~5v
Fiber Connector: LC/UPC, LC/APC, SC/UPC Etc. Port: 1x1
Application: Configurable OADM Control Type: Latched Or Non-Latched



Optical Route

Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching 0





Product packaging



Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching 1  Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching 2Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching 3

           Finished Item           Inner Package                      Carton







Specifications

Parameters Unit GZ-FSW-1×1
Wavelength Range nm 850±40 /1300±40 1260~1650
Operating Wavelength nm 850 / 1300 1310/1550
Insertion Loss dB Typ:0.5 Max:0.8 Typ:0.5 Max:0.8
Return Loss dB MM≥30 SM≥50
Crosstalk dB MM≥65 SM≥70
PDL dB ≤0.05
WDL dB ≤0.25
TDL dB ≤0.25
Repeatability dB ≤±0.02
Power supply v 3.0 or 5.0
Lifetime Time ≥107
Switch Time ms ≤8
Transmission Power mW ≤500
OperatingTemperature -20~+70
Storage Temperature -40~+85
Weight g 16
Dimension mm (L)27.0×(W)12.0×(H)8.2







Product Overview

Low Insertion Loss 1X1 Mechanical Optical Switch Latching / Non-Latching



1x1 Optical Switch



Gezhi 1x1 Opto-Mechanical Bi-directional Fiber Optic Switch connects optical channels by redirecting 1 incoming optical signals into 1 output fibers. This is achieved using a opto-mechanical configuration and activated via an electrical control signal. The switch has integrated electrical position sensors.

Based on thin film filter technology that provides a robust method of altering the light patch, this series of products has a drastically simplified platform configuration offering high reliability and low production cost. This novel design significantly reduces moving part position sensitivity, offering unprecedented high stability as well as an unmatched low cost.









Features

Low Insertion loss

Wide Wavelength Range

Low Crosstalk

High Stability, High Reliability

Epoxy-free on Optical Path

Latching and Non-latching







Applications

WDM Network

Line Monitoring

Telecommunication

Testing Instrument
