1x2 Mechanical Optical Switch module ,Non-latching Fiber Optic Switch

Name: 1x2 Mechanical Optical Switch module ,Non-latching Fiber Optic Switch
Brand: Gezhi Photonics (Shenzhen) Technology Co., Ltd.
SKU: 1x2 Optical Switch Module
Price: 360.00 USD
Availability: InStock

Brand Name:	GEZHI or OEM
Model Number:	1x2 Optical Switch Module
MOQ:	1pc
Price:	Negotiable
Delivery Time:	5-8 work days
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE RoHS,ISO9001

Port:

1x2

Control Type:

Latched Or Non-Latched

Condition:

100% New

Warranty:

3 Years

Name:

1x2 Optical Switch Module

Fiber Connector:

LC/UPC, LC/APC, SC/UPC Etc.

Packaging Details:

Paper box

Supply Ability:

100000Channel per month

Highlight:

Mechanical Optical Switch module

1x2 Fiber Optic Switch

1x2 Mechanical Optical Switch module

Product Description

Optical Route

Status One

Status Two

1x2 Mechanical Optical Switch module ,Non-latching Fiber Optic Switch 0

1x2 Mechanical Optical Switch module ,Non-latching Fiber Optic Switch 1

Similar Products

1x2 Mechanical Optical Switch module ,Non-latching Fiber Optic Switch 2

1x2 optical switch

1x1 optical switch

1x4T optical switch

Specifications

Parameters		GZ-FSW-1×2
Wavelength Range	nm	850±40 / 1300±40	1260~1650
Operating Wavelength	nm	850/1300	1310/1490/1550/1625/1650
Insertion Loss	dB	Typ:0.8 Max:1.2	Typ:0.5 Max:1.0
Return Loss	dB	MM≥30 SM≥50
Crosstalk	dB	MM≥35 SM≥55
PDL	dB	≤0.05
WDL	dB	≤0.25
TDL	dB	≤0.25
Repeatability	dB	≤±0.02
Power Supply	V	3.0 or 5.0
Lifetime	Time	≥107
Switch Time	ms	≤8
Transmission Power	mW	≤500
Operating Temperature	℃	-20~+80
Storage Temperature	℃	-40~+85
Weight	g	16
Dimension	mm	(L)27×(W)12.0×(H)8.2

Product Overview

1x2 Mechanical Optical Switch module ,Non-latching Fiber Optic Switch

1x2 Optical Switch

GEZHI 1x2 Mechanical Optical Switch connects optical channels by redirecting an incoming

optical signal into a selected output fiber.

GEZHI 1x2 Mechanical Optical Switch support all wavelength at 1260nm~1650nm, it offers

ultra-high reliability, low insertion loss, fast switching speed as well as bi-directional performance.

The optical switches are widely used for Optical Network, Protection, Transmitter and Receiver

Protection,Network Test System and Instrumentations.

Features

Low Insertion loss

Wide Wavelength Range

Low Crosstalk

High Stability, High Reliability

Epoxy-free on Optical Path

Latching and Non-latching

Applications

WDM Network

Line Monitoring

Telecommunication

Testing Instrument
