Payment & Shipping Terms:
|Data Rate:||40G||Certification:||CE RoHS FCC|
|Use:||FTTH FTTB FTTC||Distance:||10km|
|Storage Temperature:||-40 ~+85 ℃||Network Distance::||Wireless Lan, Wired LAN, TCP, Ip, POE, Wifi|
40g Qsfp+ Lr4 10km 1310nm Lc Connector Fiber Optical Transceiver Module Cwdm 40g Qsfp Qsfp-40g-lr4
QSFP-40G-LR4 Compatible 40G QSFP+ 1310nm 10km Duplex LC DDM Transceiver
The QSFP-40G-LR4 QSFP+ Optical Transceiver Module is designed for use in 40GBASE Ethernet throughput up to 10km over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors. This transceiver is compliant with QSFP+ MSA and IEEE 802.3ba 40GBASE-LR4 and OTU3 C4S1-2D1 standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP+ MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as data centers, high-performance computing networks, enterprise core and distribution layer applications.
◈ Hot Pluggable QSFP+ Form Factor◈ Max. Power Consumption 1.3W
◈ High-Speed Electrical Interface Compliant to IEEE 802.3ba
◈ Support 40G to 4x10G Breakout Application
◈ Compliant to SFF-8436 and QSFP MSA
◈ Class 1 Laser Safety and RoHS Compliant
◈ Digital Optical Monitoring Capability for Strong Diagnostic Capabilities
◈ RoHS compliance
◈ Operating temperature range: 0~70°C(Commercial)
◈40GBASE-LR4 40G Ethernet links
◈Infiniband QDR, DDR and SDR
◈Datacenter and Enterprise networking
Packing & Shipping
1. Can I have a sample order?What is your MOQ?
Yes, we welcome sample order to test and check quality. We do not have MOQ,1 sample is available.
2. What is the lead time?
For usual products,We keep stock,could ship about 3 days after received payment.For big quantity and special products,Please check lead time with our sales representative.
3. What is your payment terms?
Usually,we need prepayment by T/T,West Union or Paypal.
Could also support L/C,Credit terms.
4. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive.
5. What is your warranty time
We promise 3 years warranty for all products shipped from us.
6. Could i use our own logo and label?
Yes,we could provide a OEM service and make the products with your own label.
7. Could I return the products if there is a quality problem?
Yes,if there is a quality problem happen,we could accept free exchange.
