Good price online

products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Polarization Maintaining Components
Created with Pixso. 1310nm Single Mode Fiber Optic Circulator with High Isolation for Bidirectional Signal Transmission
1310nm Single Mode Fiber Optic Circulator with High Isolation for Bidirectional Signal Transmission
  • name
  • name
  • name
  • name
  • name

1310nm Single Mode Fiber Optic Circulator with High Isolation for Bidirectional Signal Transmission

Brand Name: GEZHI or OEM
Model Number: 1310 nm Optical Fiber Circulator
MOQ: 1pc
Price: US$288-US$988
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Connector Type:
FC/PC Connectors/ FC/APC Connectors
Packaging Details:
Paper box
Highlight:

Fiber Optic Splitter Circulators

,

1310nm Optical Fiber Circulator

,

SM Optical Fiber Circulator

Product Description
SM Fiber Optic Splitter Circulators 1310nm Optical Fiber Circulator Single Mode Type
Product Overview

1310 nm SM Fiber Optic Circulators are available unterminated, with FC/PC connectors, or with FC/APC connectors. Circulators can be used to send optical signals through a single fiber in two directions. An optical circulator is analogous to an electronic circulator and both perform similar functions.

An optical circulator is a three-port device that allows light to travel in only one direction. A signal entering Port 1 will exit Port 2 with minimal loss, while a signal entering Port 2 will exit Port 3 with minimal loss. Light entering port 2 experiences a large amount.

Key Features
  • High isolation & High Return Loss
  • Low insertion loss & PDL
  • Optical Path Epoxy Free
Applications
  • Add-Drop Multiplexing
  • Fiber Sensors
  • Bidirectional Pumping
  • Bidirectional Signal Transmission Systems
  • Coupling In-Line Chromatic Dispersion Compensation Devices
Technical Specifications
Item Unit Parameters
Operating wavelength nm 1064
Bandwidth nm ±5 | ±10 | ±20 | ±30
Isolation dB ≥25 | ≥23 | ≥20 | ≥20
Insertion Loss@Band,23℃ dB ≤2.1 | ≤2.6 | ≤3.2 | ≤3.8
PDL dB ≤0.2
Return Loss dB ≥ 50
Cross Talk dB ≥ 45
PDL dB ≤ 0.1
Maximum Optical Power mW ≤ 300
Operation Temperature °C 0~50
Storage Temperature °C -40~85
Package Dimension mm 34x8.4x8.4(P1)
Dimensions
1310nm Single Mode Fiber Optic Circulator with High Isolation for Bidirectional Signal Transmission 0
Ordering Information
Wavelength Bandwidth Fiber Type Fiber Length Connector Type
1. 1064nm
2. Others		 1. ±5nm
2. ±10nm
3. ±20nm
4. ±30nm		 1. 250μm fiber
2. 900μm fiber
3. Others		 1. 0.5 +/- 0.1 m
2. 1.0 +/- 0.1 m
3. Others		 0. No Connector
1. FC/UPC
2. FC/APC
3. SC/UPC
4. SC/APC
5. LC/PC
6. MU/PC
7. Others
Tags:

Polarization Maintaining Components

polarization maintaining isolator

polarization maintaining optical circulator
