Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc

Large Image : Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc

Product Details:

Place of Origin:	China
Brand Name:	GEZHI or OEM

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	Negotiable
Packaging Details:	2pcs in a foam with plastic Box
Delivery Time:	2-7 work days
Payment Terms:	T/T, Western Union
Supply Ability:	50000pcs per month

Contact Now

Detailed Product Description

Certification:	RoHS	Model Number:	MPO Patch Cord XX
Color:	Customized	Connector:	MPO
Insertion Loss:	0.2db	Outer Jacket:	LSZH,OFNP ,OFNR
Warranty Time:	3years	Cable Length:	1/3/5m...or Customized
High Light:	1m sc apc patch cord , sc custom fiber optic patch cables , sm custom fiber optic patch cables

Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc 0 Customized Length Optical Fiber Patch Cord SC SC SM/MM/OM3 PVC/OFNR/LSZH UPC/APC

Product View

Fiber Optic Patch Cord have same or different connectors which are installed on the end of fiber optic cable. The Fiber Optic Patch Cord series comes with a comprehensive collection of lengths and connectors to fulfill your demand for the deployment

Features

Low Insertion Loss

High return Loss
Factory-terminated and Tested

Applications

Telecom
Optical Fiber Test Equipment
Optical Fiber Communication System
FTTH,LAN,PON & Optical CATV.

Ordering options
Connector type: FC, SC, LC, ST, MTRJ, MU, MPO, DIN, D4, SMA
Ferrule End-face: PC, UPC, APC
Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
Cable Quantity: Simplex, Duplex, 6cores ,12corns, 16cores, 24cores, 36cores, 48cores...
Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
Cable Length: 1, 2, 3 meter or customized
Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum ,Armored

Specification

Item	SM			MM
Type	FC/APC	FC/UPC	FC/APC	FC/UPC
	SC/APC	SC/UPC	SC/APC	SC/UPC
	ST/APC	ST/UPC
Return Loss	>=45dB	>=50dB	>=60dB	>=35dB
Insertion Loss	<=0.2dB
Operating Temperature	-40°C ~ +80°C
Repeatability	<=0.1dB
Interchangeability	<=0.2dB
Insertion and Pull Times	1000
Tensile Strength	>100N

Application Diagram

Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc 3

Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc 4

Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc 5

Quality Control

Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc 6

Our Certificate

Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc 7

Packing & Shipping

Length Custom Fiber Optic Patch Cables Sc Sm / Mm / Om3 Pvc / Upc / Apc 8

AFQ

Q1:Can I have a sample order? What is your MOQ?

A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available.  Also Mixed samples are acceptable.

Q2: What's the Lead time?

A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.

Q3: What are the payment terms?

A3: Payment term: T/T, Paypal, Western union,cash payment, Alibaba etc.

Q4: Could I use our own logo, label and package?

A4: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.

Q5: What is your warranty time

A5: 3 years' warranty.
