Patch Cable Series
Created with Pixso. Telecom Communication Armored Fiber Patch Cable With Sc / Upc / Pc Connector

Telecom Communication Armored Fiber Patch Cable With Sc / Upc / Pc Connector

Brand Name: GEZHI or OEM
Model Number: Fiber optic patch cord
MOQ: 1pc
Price: Negotiable
Delivery Time: 2-7 work days
Payment Terms: T/T, Western Union
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Application:
Telecom Network
Model Number:
UPC-LC UPC-SM-DXXX
Use:
FTTx Solutions
Cable Length:
1m 3m 5m Or Customized
Insertion Loss:
<0.2dB
Warranty Time:
3 Year
Tensile Strength(N):
≥90(3.0mm );≥70(0.9mm 2.0mm)
Cable Diameter:
0.9/2.0/3.0mm
Return Loss:
UPC>50dB;APC>60dB
Packaging Details:
2pcs in a foam with plastic Box
Supply Ability:
50000pcs per month
Highlight:

telecom communication armored fiber patch cable

,

upc connector armored fiber patch cable

Product Description

Ftth Armored Patchcord Om1 Duplex Jumper Sc/lc/fc/st Fiber Optic Patch Cord

Product View

The armoured fibre optic patch Cords are designed for being used in harsh environment, in which the traditional standard fibre optic patch lead can not perform structurally to the requirement.The armoured fibre optic patch leads is made with special strong connectors and armoured fiber optic leads, it can protect the cable from damage caused by twist, pressure or rodent bite.

Telecom Communication Armored Fiber Patch Cable With Sc / Upc / Pc ConnectorTelecom Communication Armored Fiber Patch Cable With Sc / Upc / Pc Connector

Features

* Strong safeguard of optical fibers due to use of stainless steel material.
* High tensile strength, pressure resistant, retwist resistance, rodent protected.
* Easy handling similar to electrical cable and easy installation.
* Available with all types of connectors and fibers
* 100% factory terminated and tested



Applications

* Strong safeguard of optical fibers due to use of stainless steel material.
* High tensile strength, pressure resistant, retwist resistance, rodent protected.
* Easy handling similar to electrical cable and easy installation.
* Available with all types of connectors and fibers
* 100% factory terminated and tested







Specification

Item
Single mode
Multi mode

PC
UPC
APC
PC
Insertion Loss
≤0.3dB
≤0.3dB
≤0.3dB
≤0.3dB
Reture Loss
≥50dB
≥55dB
≥60dB
≥35dB
Repeatability
≤0.1dB
≤0.1dB
≤0.1dB
≤0.1dB
Durability(Times)
≥600
≥600
≥600
≥600
Tensile strength(N)
≥55
≥55
≥55
≥55
Operating Wavelength
1310nm,1550nm
Temperature Stability
Additional Loss≤0.2dB, Return Loss Variability<5dB
Working Temperature
-50ºC~+75ºC



Telecom Communication Armored Fiber Patch Cable With Sc / Upc / Pc Connector
