Product Details:
Payment & Shipping Terms:
|
| Certification: | RoHS | Model Number: | MPO Patch Cord |
|---|---|---|---|
| Use: | FTTX | Insertion Loss: | IL<0.2db |
| Warranty Time: | 12 Months | Connector: | MPO |
| Outer Jacket: | LSZH,OFNP ,OFNR | Length: | Customized Lengths(1m/2m/3m...+1 |
| High Light: | LSZH jacket optical patch cord,IEC Performance optical patch cord |
||
Multimode Wideband Fiber Patch Cable 2m LC To FC
Tested to TIA and IEC performance specifications3M Volition VF-45 Patch Cords use the excellent reliability and ruggedness of 3M glass/glass/polymer (GGP) fiber optic cable which is ideal for applications requiring tight bends, durability and dependability. The cable used to make Volition patch cords is grade index multimode optical fiber with 10um glass cladding diameter and 125um polymer coating diameter. The polymer is a tough permanent coating, which provides improved strength and bends resistance. The static fatigue parameter is a 50% improvement over standard life. This High strength fiber is fully compatible and intermatable with standard glass fiber.VF-45 Fiber Optic Patch Cord is designed by 3M and features plug and jack design without the need to adapters. VF-45 plug is inserted into the socket (jack) at a 45-degree angle, pressing a pair of fibers into V-grooves inside the socket. This design of VF-45 Connector eliminates the need for expensive ferrules thus reduce connector costs.
|
Features VF-45 Connector is half the size of the SC Connector VF-45 Optical Connector works on standard 62.5µm or 50µm multimode fiber RJ-45 style latch for ease of use and familiarity |
Applications Interconnect socket (field terminated)
Wall outlets and faceplates Termination and cleaning kits Test equipment |
Specification
| Item | Parameter | |
| Single-mode | Multi-mode | |
| Insertion Loss | ≤0.75dB | |
| Return Loss | ≥50 dB (SM PC),≥35 dB (MM PC) | |
| Repeatability | ≤0.1dB | |
| Durability | 0.2dB Max. 1000 mattings | |
| Operating Temperature | -40℃~+85℃ | |
| Storage Temperature | -40℃~+85℃ | |
Quality Control
Our Certificate
Packing & Shipping
AFQ
Q1:Can I have a sample order? What is your MOQ?
A3: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
