Created with Pixso. RS-232 Control 850nm Latching Mechanical Optical Switch Module for Fiber Optic Networks
RS-232 Control 850nm Latching Mechanical Optical Switch Module for Fiber Optic Networks
  • name
  • name
  • name
  • name
  • name
  • name

RS-232 Control 850nm Latching Mechanical Optical Switch Module for Fiber Optic Networks

Brand Name: GEZHI or OEM
Model Number: GZ-FSW-1x2-XM-FA
MOQ: 1pc
Price: US$69-US$150
Payment Terms: T/T,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE RoHS,ISO9001
Product Name:
1x2 Mechanical Optical Switch Module
Wavelength:
850nm
Fiber Type:
Multimode
Connector:
FC/APC
Control Type:
Latching
Control Mode:
RS-232
Package:
Module
Packaging Details:
Paper box
Supply Ability:
5000pcs per month
Highlight:

RS-232 Control Mechanical Optical Switch

,

1x2 Mechanical Optical Switch

Product Description
RS-232 Control 1x2 Mechanical Optical Switch Module
850nm Latching Optic Switches for reliable fiber optic path control and monitoring
Product Overview
The Gezhi 1x2 mechanical optical switch module is a precision light path control device designed for multi-channel fiber optic switching applications. This module enables efficient routing in optical fiber transmission systems, supporting multi-channel monitoring, source/detector selection, and optical path protection. Ideal for testing systems, cable verification, and multi-point optical sensor monitoring.
Control & Operation
The module features dual control methods via front-panel buttons and RS-232 interface, with optical path selection available through host computer software for flexible system integration.
Applications
  • Wavelength routing systems
  • Reconfigurable add/drop multiplexers
  • Optical network monitoring and testing
Key Features
  • Broad wavelength range compatibility
  • Low insertion loss for minimal signal degradation
  • Epoxy-free optical path design
  • High stability and reliability
  • Dual control via buttons and RS-232 interface
RS-232 Control 850nm Latching Mechanical Optical Switch Module for Fiber Optic Networks 0 RS-232 Control 850nm Latching Mechanical Optical Switch Module for Fiber Optic Networks 1
Technical Specifications
Parameter Unit GZ-FSW-1x2
Wavelength Range nm 532~1064nm | 1260～1650
Operating Wavelength nm 532/650/780/850/980 nm | 1310/1490/1550/1625 nm
Insertion Loss dB Typ:0.8 Max:1.2 | Typ:0.6 Max:0.8
Return Loss dB MM≥30 SM≥50
Crosstalk dB MM≥35 SM≥55
PDL dB ≤0.05
WDL dB ≤0.25
TDL dB ≤0.25
Repeatability dB ≤±0.02
Power Supply v 5V / 500mA
Control Mode / Button, RS232
Lifetime times ≥107
Switch Time ms ≤8
Transmission Power mW ≤500
Operating Temperature ℃ -20～+70
Storage Temperature ℃ -40～+85
Weight g 16
Dimension mm (L)104.0*(W)120.0*(H)28
Ordering Information
GZ-FSW-1x2-x-xx-x-x-xx
Mode Wavelength Control Model Fiber Type Connector
S=SM M=MM 85=850nm 13=1310nm 15=1550nm 13/15=1310/1550nm X=Others L=Latching N=Non-Latching 5=50/125 6=62.5/125 9=9/125 X=Others FP=FC/PC FA=FC/APC X:Others
