MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord

MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord
MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord

Large Image :  MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord

Product Details:
Place of Origin: China
Certification: CE RoHS,ISO9001
Model Number: MPO OM3-AA
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: 2pcs in a foam with plastic Box
Delivery Time: 2-7 work days
Payment Terms: T/T, Western Union
Supply Ability: 50000pcs per month
Contact Now
Detailed Product Description
Brand Name: GEZHI Or OME Connector Type: Female Or Male
Fiber Count: 12/24/48/96/144 Cores Warranty: 3 Yeas
Cable Length: Customized Outer Jacket: LSZH,OFNP,OFNR
High Light:

OM3 Fiber Optic Cable

,

Multimode Fiber Optic Cable

,

MTP/MPO Fiber Optic Cable

Product description



                                          MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord

GEZHI Photonics manufactures data center grade fiber optic MPO patch cords. The MPO connector uses a spring loaded sliding mechanism allowing the fiber patch cord to latch onto adapters providing a secure and reliable connection for network cabling in enterprise data centers, backbone, colocation facilities, server farms, cloud storage networks, and telecommunication rooms. Each assembly is 100% factory tested to meet IEC 61753-1 standard.

MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord 0

MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord 1

MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord 2



Applications

Data Center

Optical System Access network

Storage area networking

40GbE & 100GbE protocol





Specification

1. Custom Fiber Count

8 Fibers
used for 40G/100G QSFP+/QSFP28 direct connection.
12-144 Fibers
used for 10G/40G/100G high-denisty structural fiber cabling.
格致 应用�?.jpg 格致 应用�?.jpg



2. Custom Polarity





There are also three different types of MPO cables – Type A, Type B and Type C as below pictures:



MPO patchcor polarity1.jpg





3. Custom Connectors

Male (with pins)

The male connector is mated to the female side for adapters, cassettes or panels connection.

Female (without pins)

The female connector can be directly connected to transceivers or other male

connectors.

male female MPO patch cord1.jpg



Specifications

Performance Level Standard Elite
Connector Mode Endface IL(max) (dB) RL(min) (dB) IL(max) (dB) RL(min) (dB)
MPO/MTP MM OM3 8F/APC ≤0.50 ≥20 ≤0.35 ≥20
12F/APC ≤0.50 ≥20 ≤0.35 ≥20
24F/APC ≤0.50 ≥20 ≤0.35 ≥20
8F/PC ≤0.50 ≥20 ≤0.35 ≥20
12F/PC ≤0.50 ≥20 ≤0.35 ≥20
24F/PC ≤0.50 ≥20 ≤0.35 ≥20



Product line

MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord 7MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord 8MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord 9







Packing & Delivery



MPO OM3 MTP/MPO 12 Strand Multimode Fiber Optic Cable Patch Cord 10



AFQ

Q1:About the price?

A1:We usually quote within 12 hours after we confirm the technical data of your products.
Q2: What's the payment method?

A2: We accept L/C,T/T,Western Union,MoneyGram,PayPal etc.

Q3: What are your terms of payment?
A3: 30% in advance,and 70% before shipment
Q4: How to ship the items to me?
A4: Courier(DHL,TNT,FEDEX,UPS,EMS),Airfreight,Ocean Ship are available.
Q5: How long is your delivery time?
A5: The general delivery time is 5-7 days after order confirmed,it depends on the order quantity.
