1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength

1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength

Large Image :  1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength

Product Details:
Place of Origin: China
Brand Name: Gezhi or OEM
Certification: CE RoHS,ISO9001
Model Number: OSW-1x48-13/15 XX
Payment & Shipping Terms:
Minimum Order Quantity: 1 pieces
Price: USD >= 1 pieces $25
Packaging Details: inner box,Carton
Delivery Time: 7 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 Piece/Pieces per Day
Contact Now
Detailed Product Description
Model Number OSW-1x48-13/15 XX Place Of Origin Guangdong, China Brand Name GEZHI Or OEM Use System M: OSW-1x48-13/15 XX Application: FTTx Network
Fiber Connector: LC/UPC, LC/APC, SC/UPC Etc. Control Type: Latching Or Non-Latching
Voltage: 5V Or 12V Port: 1x48
Wavelength: 1260-1650nm
High Light:

62.5/125um 1x48 Optical Switch

,

1550nm 1x48 Optical Switch

Product description



                                        1x48 Optical Switch with mm 62.5/125um Fiber 1550nm Wavelength

GEZHI 1×48 Multi-Channele Fiber Optical switches is a kind of functional component, with the ability of switching optical route.
In optical fiber transmission system, it is used for multi light source/ detector selection, multi-channel fiber monitoring, and
ptical fiber path protection etc. Besides, it is also used in optical fiber test system for optical fiber and its component
test,outdoor cable test and multi-spot optical sensors monitoring system.

1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 0
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 1
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 2

Feature
Low Insertion LossMore Than 128 Channels
High Stability & Reliability
Parallel Interface (TTL)
Modularized Design
Customzied Wavelength available

PRODUCT SPECIFICATIONS
Parameter
Unit
OSW-1x48
Wavelength Range
nm
850±40/1300±40
1260~1650
Operating Wavelength
nm
850/1300
1310/1550
Insertion Loss
dB
<1.2
<1.0
Return Loss
dB
MM≥30 SM≥50
Crosstalk
dB
MM≥35 SM≥55
Polarization Dependent Loss
dB
0.05
WDL
dB
≤0.25
TDL
dB
≤0.25
Repeatability
dB
≤±0.02
Power Supply
V
5.0 or 12v
Lifetime
times
≥107
Switch Time
ms
≤8
Optical Power
mW
≤500
Operating Temperature
℃
-20~+75 (-40~+85 available)
Storage Temperature
℃
-40~+85
Dimension
mm
135×64×32



Product packaging
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 3
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 4
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 5
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 6
Finished Item
Inner Package
Inner Box
Carton



Test Enviroment
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 7
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 8
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 9
1x48 Optical Switch With 62.5/125um Fiber 1550nm Wavelength 10
NO-dust workshop
High Temp. Ageing & High-Low Temperature cycling
Relay Reliable Testing
100% Testing Before Shipment



FAQ
Q1:Can I have a sample order? What is your MOQ?
A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.
Q2: What's the Lead time?
A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.
Q3: What are the payment terms?
A3: Payment term: T/T, Paypal, Western union,cash payment, Alibaba etc.
Q4: What is your warranty time
A4: 3 years' warranty.
Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
