MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch

Large Image : MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch

Product Details:

Place of Origin:	China
Brand Name:	Gezhi or OEM
Certification:	CE RoHS,ISO9001
Model Number:	MEMS-M-1x8

Payment & Shipping Terms:

Minimum Order Quantity:	1 pieces
Price:	USD >= 1 pieces $32
Packaging Details:	inner box,Carton
Delivery Time:	7 Days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1000 Piece/Pieces per Day

Contact Now

Detailed Product Description

Application:	Multicast Switching	Fiber Connector:	LC/UPC, LC/APC, SC/UPC Etc.
Port:	1x8	Wavelength:	C-band Or Customized
Warranty Time:	3 Years	Use:	Multi-point Optical Monitoring
Brand Name:	GEZHI Or OEM
Highlight:	Fiber Sensing and Monitoring Optical Switch , Data Center MEMS Optical Switch , 1x8 MEMS Optical Switch

Product description

MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch

Gezhi Photonics MEMS 1X8 Fiber Optical Switch is a compact, single mode or multimode fiber optical switch configurable for port counts up to 1x64.It utilizes the proprietary microelectromechanical system (MEMS) technology to achieve reliable optical performance and excellent durability; This MEMS optical switch is available in any 1XN size up to 1x64.

MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch 0

MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch 1

MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch 2

MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch 3

MEMS 1x8 Module Data Center Fiber Sensing and Monitoring Optical Switch 4

Feature

Low Insertion Loss

Fast Switching Time
Compact Size
Multiple Channels-Up to 1x256 channel
High number of switching cycles over life

PRODUCT SPECIFICATIONS

Parameter	Single Mode
Wavelength range (nm)	1240~1640
Insertion loss (dB)	≤1.5 (Typ 1.0)
Crosstalk (dB)	≥ 60 (Typ 75)
Backreflection (dB)	≥ 50 (Typ 55)
Polarisation Dependent Loss (dB)	≤0.12
Switch time (ms)	≤1 (Typ 0.5)
Switching Voltage ( V )	5
Fiber Pigtail (µm)	9/125/900
Durability (cycles)	no wear out
Power Consumption (mW)	≤50 (Typ 10)
Operation temperature(℃)	0~70
Storage temperature (℃)	-40~85
Package Size (L x W x H) (mm)	80 x 50 x 9.5

Parameter	Multi-Mode
Wavelength range (nm)	700 ~ 1700
Insertion loss (dB)	≤1.5 (Typ 1.0)
Crosstalk (dB)	≥ 45 (Typ 55)
Backreflection (dB)	≥ 35 (Typ 45)
Polarisation Dependent Loss (dB)	≤0.15
Repeatabiliy (dB)	≤0.001
Switch time (ms)	≤20 (Typ 2)
Switching Voltage ( V )	5
Fiber Pigtail (µm)	62.5/125/900 or 50/125/900
Durability (cycles)	no wear out
Supply Voltage (V)	4.0~5.25 (Typ:5)
Power Consumption (mW)	≤50 (Typ 10)
Operation temperature(℃)	0~70
Storage temperature (℃)	-40 ~ 85
Package Size (L x W x H) (mm)	80 x 50 x 9.5

Test Environment

NO-dust workshop

High Temp. Ageing & High-Low Temperature cycling

Relay Reliable Testing

100% Testing Before Shipment

FAQ

Q1:Can I have a sample order? What is your MOQ?

A1:Sample order is welcome to test and check quality. We don't MOQ, 1pcs sample is available. Also Mixed samples are acceptable.

Q2: What's the Lead time?

A2: The normal lead time is about 1week, For big quantity and special products. Please check lead time with our sales representative. But we keep stock for some products, could ship 1-3 days after receiving payment.

Q3: What are the payment terms?

A3: Payment term: T/T, Paypal, Western union,cash payment, Alibaba etc.

Q4: What is your warranty time
A4: 3 years' warranty.

Q5: Could I use our own logo, label and package?
A5: Yes, we could provide OEM service which according to your requirements, design products label, logo, PN, SN, package.
