Product Details:
Payment & Shipping Terms:
|
| Key Words: | DWDM Mux | Channel: | 8 Channels |
|---|---|---|---|
| Package: | 1U 19'' Racks Or ABS Box Optional | Fiber Type: | SMF-28e Or Customer Specified |
| Application: | WDM Solution | Warranty: | 3 Years |
| High Light: | 2x8CH dwdm mux demux,1U dwdm mux demux,19" dwdm mux |
||
2x8CH DWDM MUX DEMUX 1U 19'' Rack LC/APC C43-C50 Channel DWDM Device Optical Equipment
Product Description
DWDM MUX/DEMUX reduce the cost of network Construction. With low-cost and compact dimension, it is mainly used in metropolitan area network and access layer, also be used to build networks.
Features
Applications
Performance Specifications
| Parameters | |||||||
| Channel Space (GHz) | 100 | 200 | |||||
| Channel Number | 1*4 | 1*8 | 1*16 | 1*4 | 1*8 | 1*16 | |
| Center Wavelength (nm) | ITU Grid | ||||||
| Center Wavelength Accuracy (nm) | ± 0.05 | ± 0.1 | |||||
| Channel Passband (@-0.5dB) (nm) | 0.22 | 0.5 | |||||
| Fiber Type | SMF-28e with 900um loose tube or customer specified | ||||||
| IL (dB) | 1.8 | 2.3 | 3.0 | 1.7 | 2.9 | 3.1 | |
| Passband Ripple (dB) | 0.35 | 0.4 | 0.5 | 0.35 | 0.4 | 0.5 | |
| Isolation (dB) | Adjacent Channel | 25 | 28 | ||||
| Non-Adjacent Channel | 40 | ||||||
| PDL (dB) | 0.2 | ||||||
| PMD (ps) | 0.1 | ||||||
| RL (dB) | 45 | ||||||
| Directivity (dB) | 50 | ||||||
| Maximum Optical Power (mw) | 500 | ||||||
| Operating Temperature (°C) | -40~85 | ||||||
| Storage Temperature (°C) | -40~85 | ||||||
| BOX Package (mm) | 100*80*10 or 140*115*18 | ||||||
| LGX Package | 1U,2U | ||||||
| 19’’ Rack mount Package | 1U | ||||||
Order details
2~44Channels available.
Com port: simplex or duplex.
Fiber connector: LC/SC or other.
Package: ABS plastic box, LGX metal cassette box, 19inch rack mount.
DWDM Solutions and DWDM SFP/XFP.
Min.Order Quantity: 1pcs is also okay for sample to satisfy your need.
DWDM Mux/Demux Solution
DWDM Mux/demux with EDFA
